Additional Information
-
Hydraulic steering
Stainless Steel ski pole
Stainless Steel bow rail
Stainless Steel folding extending ladder
Stainless Steel cockpit grab rails
Stainless Steel rod holders
Alloy Fuel Tank
CompassToughened glass windscreen
Cockpit Rod Racks
Teak coaming treads
Toughened glass windscreen
Screen grab rail
Toilet compartment
Burl elm dash panel
Fibreglass hull liner
Polymer upholstery panel boards
Polyurethane foam filled hull
NZ CPC Standard
-
Infill squab
Rope chain capstan
Trim tabs
Bait Station
Flexi teak floor and hatch
Road Cover
Rocket launcher with rigid frame, bimini and clears
Chemical Toilet
Screen grab rail
Electronics (Fish finder, VHF)
Classic hull band
Specifications
| Model: | 530 | 565 | 605 | 635 |
| LOA: | 5.600m | 5.910m | 6.460m | 6.765m |
| Hull Length: | 5.218m | 5.670m | 6.050m | 6.325m |
| Beam: | 2.145m | 2.290m | 2.290m | 2.420m |
| Deadrise: | 21 deg | 23 deg | 22.5 deg | 21 deg |
| No people: | 5 / 375 kgs | 6 / 450 kgs | 7 / 525 kgs | 7 / 525 kgs |
| Height on Trailer: | 2.200m | 2.250m | 2.250m | 2.350m |
| Length on Trailer: | 6.800m | 7.100m | 7.500m | 7.600m |
| Width on Trailer: | 2.370m | 2.450m | 2.450m | 2.450m |
| Bunk Length: | - | 1.800m | 1.920m | 2.000m |
| Fuel Capacity (approx): | 95 litres | 165 litres | 165 litres | 240 litres |
| Dry Hull Weight (approx): | 670 kg | 830 kg | 960 kg | 1050 kg |
| Total Road Weight (approx): | 1185 kg | 1440 kg | 1670 kg | 1840 kg |
| Maximum Horse Power: | 130 hp | 150 hp | 200 hp | 250 kg |
| Maximum Engine Weight: | 198 kg | 220 kg | 239 kg | 269 kg |
